MX-3114N SIMULATION 6 – 27
* The winding counter for the fusing web cleaning is cleared by
being synchronized with the fusing web cleaning feed counter.
24-5
Purpose
Data clear
Function (Purpose)
Used to clear the developer counter. (After
replacement of developer, clear the
counter.)
Section
Operation/Procedure
1) Select the item to be cleared with the touch panel key.
2) Press [EXECUTE] key.
3) Press [YES] key.
The target counter is cleared.
When SIM25-2 is executed, this counter is also cleared automati-
cally.
Fusing FUSING BELT Fusing belt (Counter)
Fusing belt (Number of use days)
Fusing belt
(Accumulated number of rotations)
FUSING
ROLLER
Fusing roller (Counter)
Fusing roller (Number of use days)
Fusing roller
(Accumulated number of rotations)
PRESS
ROLLER
Pressure roller (Counter)
Pressure roller (Number of use days)
Pressure roller
(Accumulated number of rotations)
FUSING LOAD Fusing Pressure release roller
(Accumulated number of rotations)
Separation SEPARATE
PAWL
Separation pawl (Counter)
Separation pawl (Number of use days)
Separation pawl
(Accumulated number of rotations)
SEPARATE
PLATE
Separation plate (Counter)
Separation plate (Number of use days)
Separation plate
(Accumulated number of rotations)
FUSING WEB Fusing web unit print counter
Use day of fusing web unit
Fusing web cleaning send counter
CLEANING
ROLLER (for
23cpm
machine)
Cleaning roller (Counter)
Cleaning roller (Number of use day)
Cleaning roller (Accumulated number of
rotation)
Transfer TC1 BELT Primary transfer belt (Counter)
Primary transfer belt
(Number of use days)
Primary transfer belt
(Accumulated number of rotations)
TRANS BLADE Transfer blade (Counter)
Transfer blade (Number of use days)
Transfer blade
(Accumulated number of rotations)
TC2 BELT Secondary transfer belt (Counter)
Secondary transfer belt
(Number of use days)
Secondary transfer belt
(Accumulated number of rotations)
PTC PTC counter (Counter)
PTC counter (Number of use days)
PTC counter
(Accumulated number of rotations)
Drum DRUM CTRG K Drum cartridge (K) (Counter)
Drum cartridge (K) (Number of use days)
Drum cartridge (K)
(Accumulated number of rotations)
DRUM CTRG C Drum cartridge (C) (Counter)
Drum cartridge (C)
(Number of use days)
Drum cartridge (C)
(Accumulated number of rotations)
DRUM CTRG M Drum cartridge (M) (Counter)
Drum cartridge (M)
(Number of use days)
Drum cartridge (M)
(Accumulated number of rotations)
DRUM CTRG Y Drum cartridge (Y) (Counter)
Drum cartridge (Y)
(Number of use days)
Drum cartridge (Y)
(Accumulated number of rotations)
Item/Display Content
Main
charger
MAIN
CHARGER K
Main charger (K) (Counter)
Main charger (K) (Number of use days)
Main charger (K)
(Accumulated number of rotations)
MAIN
CHARGER C
Main charger (C) (Counter)
Main charger (C) (Number of use days)
Main charger (C)
(Accumulated number of rotations)
MAIN
CHARGER M
Main charger (M) (Counter)
Main charger (M) (Number of use days)
Main charger (M)
(Accumulated number of rotations)
MAIN
CHARGER Y
Main charger (Y) (Counter)
Main charger (Y) (Number of use days)
Main charger (Y)
(Accumulated number of rotations)
Drum blade DRUM BLADE
K
Drum blade K (Counter)
Drum blade K (Number of use days)
Drum blade K
(Accumulated number of rotations)
DRUM BLADE
C
Drum blade C (Counter)
Drum blade C (Number of use days)
Drum blade C
(Accumulated number of rotations)
DRUM BLADE
M
Drum blade M (Counter)
Drum blade M (Number of use days)
Drum blade M
(Accumulated number of rotations)
DRUM BLADE
Y
Drum blade Y (Counter)
Drum blade Y (Number of use days)
Drum blade Y
(Accumulated number of rotations)
Other PS PAPER PS paper dust cleaner (Counter)
PS paper dust cleaner
(Number of use days)
OZONE FILTER Ozone filter (Counter)
Ozone filter (Number of use days)
K
Developer cartridge print counter (K)
Accumulated number of rotations of the developer cartridge (cm) (K)
Number of day that used developer (Day) K
C
Developer cartridge print counter (C)
Accumulated number of rotations of the developer cartridge (cm) (C)
Number of day that used developer (Day) C
M
Developer cartridge print counter (M)
Accumulated number of rotations of the developer cartridge (cm) (M)
Number of day that used developer (Day) M
Y
Developer cartridge print counter (Y)
Accumulated number of rotations of the developer cartridge (cm) (Y)
Number of day that used developer (Day) Y
Item/Display Content
