MX-3114N SIMULATION 6 – 37
27
27-1
Purpose
Setting
Function (Purpose)
Used to set non-detection of communica-
tion error (U7-00) with RIC. (FSS function)
Section
Operation/Procedure
1) Enter the set value with 10-key.
2) Press [OK] key.
The set value in step 1) is saved.
27-2
Purpose
Setting
Function (Purpose)
Used to set the sender's registration num-
ber and the HOST server telephone num-
ber. (FSS function)
Section
Operation/Procedure
1) Select an item to be set with touch panel.
[USER FAX NO] [SERVA TEL NO]
2) Enter the set value with 10-key.
3) Press [SET] key.
The set value in step 2) is saved.
27-4
Purpose
Setting
Function (Purpose)
Used to set the initial call and toner order
auto send. (FSS function)
Section
Operation/Procedure
1) Select an item to be set with scroll keys.
2) Enter the set value with 10-key.
3) Press [OK] key.
The set value in step 2) is saved.
0 Not detection
1 Detection
USER FAX_NO. Sender registration number (Max. 16 digits)
SERVA TEL_NO. Host server telephone number (Max. 16 digits)
• If the connection process is not completed
normally when registering the FSS, calling to the
HOST may be continuously made every time
when the power is turned ON (from OFF) or
rebooted.
In this case, enter "********" to inhibit calling to the
HOST.
Item/Display Content
Setting
range
Default
value
Remarks
A FSS MODE NEB1 Set the FSS MODE Exclusive for send in NE-B mode 0 - 3 0 1
NEB2 Send/Receive in NE-B mode 1
NFB1 Exclusive for send in NE-F mode 2 For convenience
stores
NFB2 Send/Receive in NE-F mode 3 For convenience
stores
B RETRY_BUSY Resend number setting when busy 0 - 15 2 0: No retry
C TIMER(MINUTE)_BUSY Resend timer setting (minute) when busy 1 - 15 3
D RETRY_ERROR Resend number setting when error 0 - 15 1 0: No retry
E TIMER(MINUTE)_ERROR Resend timer setting (minute) when error 1 - 15 1
F FAX RETRY Resend number setting when FAX initial connection 0 - 15 2 Unit: Number of times
