MX-3114N SIMULATION 6 – 43
*1: Displayed, but not installed in some models.
33
33-2
Purpose
Data clear
Function (Purpose)
Used to delete the ID (IDM) information of
Felica card.
Section
Operation/Procedure
1) Press [EXECUTE] key.
2) Press [YES] key.
The ID (IDM) information of Felica card is deleted.
40
40-2
Purpose
Adjustment/Setup
Function (Purpose)
Manual paper feed tray paper width sensor
adjustment.
Section
Paper feed
Operation/Procedure
1) Open the manual paper feed guide to the max. width (MAX).
2) Press [EXECUTE] key.
The max. width (MAX) detection level is recognized.
3) Open the manual paper feed guide to P1 width (A4).
4) Press [EXECUTE] key.
The P1 width (A4) detection level is recognized.
5) Open the manual paper feed guide to P2 width (A4R).
6) Press [EXECUTE] key.
The P2 width (A4R) detection level is recognized.
7) Open the manual paper feed guide to the min. width (MIN).
8) Press [EXECUTE] key.
The min. width (MIN) detection level is recognized.
When the above operation is not performed normally, "ERROR" is
displayed. When completed normally, "COMPLETE" is displayed.
40-7
Purpose
Adjustment/Setup
Function (Purpose)
Used to set the adjustment value of the
manual paper feed tray paper width sensor.
Section
Paper feed
Operation/Procedure
1) Select a target item to be adjusted with scroll keys.
2) Enter the set value with 10-key.
3) Press [OK] key.
The set value in step 2) is saved.
41
41-1
Purpose
Operation test/check
Function (Purpose)
Used to check the operations of the docu-
ment size sensor and the control circuit.
Section
Operation/Procedure
The operating conditions of the sensors and detectors are dis-
played.
The sensors and the detectors which are turned ON are high-
lighted.
41-2
Purpose
Adjustment
Function (Purpose)
Used to adjust the document size sensor
detection level.
Section
Operation/Procedure
1) Open the document cover, and press [EXECUTE] key without
place a document on the document table.
The sensor level without document is recognized.
2) Set A3 (11" x 17") paper on the document table, and press
[EXECUTE] key.
The sensor level when detecting the document is displayed.
When the above operation is normally completed, it is displayed.
41-3
Purpose
Operation test/check
Function (Purpose)
Used to check the operations of the docu-
ment size sensor and the control circuit.
Section
Operation/Procedure
The detection output level (A/D value) of OCSW and the document
sensor (PD1 - PD7) is displayed in real time.
The light receiving range of PD1 - PD7 is 1 - 255. (Default: 128)
CSS2SET Desk installation detection
MPLD Paper length detector (Manual paper feed tray)
MPED Paper empty sensor (Manual paper feed tray)
MAX POSITION Manual feed max. width
P1(A4)POSITION Manual feed P1 position width (A4)
P2(A4R)POSITION Manual feed P2 position width (A4R)
MIN POSITION Manual feed min. width
Item/Display Content
Default
value
A MAX POSITION Manual feed max. width 241
B P1 (A4) POSITION Manual feed P1 position width (A4) 231
C P2 (A4R) POSITION Manual feed P2 position width
(A4R)
140
D MIN POSITION Manual feed min. width 19
OCSW Document cover status Open: Normal display
Close: Highlighted
PD1 - 7 Document detection
sensor status
No document: Normal display
Document present: Highlighted
Item/Display Content Detection level range
OCSW Original cover SW 0-1 ("1" to Close)
PD1 Document detection 1 0 - 255
PD2 Document detection 2 0 - 255
PD3 Document detection 3 0 - 255
PD4 Document detection 4 0 - 255
PD5 Document detection 5 0 - 255
PD6 Document detection 6 0 - 255
PD7 Document detection 7 0 - 255
