MX-3114N SIMULATION 6 – 119
67-27
Purpose
Adjustment/Setup
Function (Purpose)
Used to set the service target of the printer
mode auto color balance adjustment.
Section
Printer
Operation/Procedure
1) Press [SETUP] key on the touch panel.
2) Place the printed color balance adjustment pattern sheet
printed in SIM 67-25 on the document table.
3) Press [EXECUTE] key.
The patch image of the adjustment pattern sheet is scanned.
4) Press [OK] key.
The service target of the printer mode auto color balance
adjustment is set according to the scanned adjustment pattern
sheet patch images.
The registered color balance and the density are displayed.
Select a target color with [C] [M] [Y] [K] key.
This simulation is executed only when the printer color balance is
manually adjusted.
67-28
Purpose
Adjustment/Setup
Function (Purpose)
Used to set the default of the service target
of the printer mode auto color balance
adjustment.
Section
Printer
Operation/Procedure
1) Press [EXECUTE] key.
2) Press [YES] key.
The service target of the printer mode auto color balance
adjustment is set to the default.
The service color balance target and the color balance target
for the user color balance adjustment are set to the same color
balance as the factory color balance target.
67-31
Purpose
Data clear
Function (Purpose)
Used to clear the printer calibration value.
Section
Printer
Operation/Procedure
1) Press [EXECUTE] key.
2) Press [YES] key.
The printer calibration data (Halftone correction data) are
cleared.
(The printer color balance correction is canceled.)
67-33
Purpose
Adjustment/Setup
Function (Purpose)
Used to change the gamma of the printer
screen.
Section
Printer
Operation/Procedure
1) Select a target change color with [K] [C] [M] [Y] key on the
touch panel.
2) Select a target screen with [SCREEN] key.
3) Select a target adjustment density level with scroll key.
4) Enter the set value with 10-key.
5) Press [OK] key. (The set value is saved.)
When [EXECUTE] key is pressed, the check pattern in printed in
the color balance and density corresponding to the adjustment
value.
PCL/PS printer
GDI Printer
B Point B target value
C Point C target value
D Point D target value
E Point E target value
F Point F target value
G Point G target value
H Point H target value
I Point I target value
J Point J target value
K Point K target value
L Point L target value
M Point M target value
N Point N target value
O Point O target value
BASE Background sampling value
Item/Display Content
Setting
range
Default
value
A POINT1 Point 1 0 - 255 128
B POINT2 Point 2 0 - 255 128
C POINT3 Point 3 0 - 255 128
D POINT4 Point 4 0 - 255 128
E POINT5 Point 5 0 - 255 128
F POINT6 Point 6 0 - 255 128
G POINT7 Point 7 0 - 255 128
H POINT8 Point 8 0 - 255 128
I POINT9 Point 9 0 - 255 128
J POINT10 Point 10 0 - 255 128
K POINT11 Point 11 0 - 255 128
L POINT12 Point 12 0 - 255 128
M POINT13 Point 13 0 - 255 128
N POINT14 Point 14 0 - 255 128
O POINT15 Point 15 0 - 255 128
P POINT16 Point 16 0 - 255 128
Q POINT17 Point 17 0 - 255 128
Display Content
SCREEN1 600dpi 1bit Photo
SCREEN2 600dpi 1 bit Graphics
SCREEN3 600dpi 4 bit Photo
SCREEN4 600dpi 4 bit Graphics
SCREEN7 B/W 600dpi 1 bit
SCREEN8 B/W 600dpi 4 bit
SCREEN10 Gloss
Display Content
SCREEN1
600dpi 1bit Low (Photo)
Gloss 600dpi 1bit
SCREEN2 600dpi 1bit High (Graphics)
SCREEN7 B/W 600dpi 1bit
