MX-3114N MAINTENANCE 9 – 16
Greasing
Greasing is not always required for every maintenance. In the following cases, check and grease.
• When there are some noises.
• When a lot of jams occur frequently. (Check the jam history.)
For the part code of grease to be used, refer to "[15] TOOL LIST."
Cleaning of sensors and detectors in the paper feed/transport system
Cleaning of sensors and detectors in the paper feed/transport system is not always required for every maintenance. In the following cases,
check and clean.
• When a trouble or a jam occurs due to a sensor or a detector. (Check the jam history.)
Torque limiter check and replacement
Torque limiter check and replacement is not always required for every maintenance. In the following cases, check and replace.
• When there are some noises.
• When a lot of jams occur frequently. (Check the jam history.)
Alcohol for cleaning
Be sure to use ethanol for cleaning.
Option
name
Parts work
sequence
Part name
When
calling
At the
machine cycle
Remark
Finisher 1 Staple cartridge ✕✕Replacement is made by the user at every 5,000 pcs.
2 Staple unit ✕✕Replacement reference: Replace the unit at every
200K staple.
3 Paddle ✕ 
4 Inlet port paper transport roller ✕ 
5 Inlet port paper transport roller B ✕ 
6 Discharge brush ✕✕
7 Paper exit roller B ✕ 
8 Paper exit roller ✕ 
9 Bundle exit paper transport roller ✕ 
10 Bundle exit paper exit transport roller B ✕ 
11 Scraping roller ✕  Replacement reference: Replace at every 1000K of
the finisher paper exit count value.
12 Sensors ✕✕
– Paper guides ✕  Clean with alcohol.
Punch unit 1 Punch unit ✕✕Replacement reference: Replace the unit at every
1000K.
2Sensors ✕✕
