Sharp MX-2314N Service Manual

MX-3114N MAINTENANCE 9 – 29
26 cpm/31 cpm machine
Unit name
Parts work
sequence
Part name
When
calling
200
K
300
K
400
K
600
K
800
K
900
K
1000
K
1200
K
Remark
Manual paper
feed unit
1 Paper feed roller ✕  –   – Replace at 100K of the manual
paper feed counter or 1 year of
use.
2 Separation roller ✕  –   – 
3 Torque limiter ✕✕– ✕✕✕ – ✕✕
4 Transport roller 9 ✕  –   – 
5 Transport roller 10 ✕  –  – 
6Sensors ✕✕– ✕✕ ✕ – ✕✕
– Paper guides –   – Clean with alcohol.

