Sharp MX-2314N Service Manual

MX-3114N MAINTENANCE 9 – 30
H. Tray paper feed section
23 cpm machine
26 cpm/31 cpm machine
Unit name
Parts work
sequence
Part name
When
calling
100
K
200
K
300
K
400
K
500
K
600
K
700
K
800
K
Remark
Tray paper
feed unit
1 Paper pickup roller ✕     Replace at 100K of the tray
paper feed counter or 1 year of
use.
2 Paper feed roller ✕      
3 Separation roller ✕      
4 Transport roller 4 ✕      
5 Transport roller 2 ✕      
6 Torque limiter ✕✕✕✕✕✕✕✕✕
7 Sensors ✕✕✕✕✕✕✕✕✕
– Paper guides ✕      Replace at 100K of the tray
paper feed counter or 1 year of
use.
Unit name
Parts work
sequence
Part name
When
calling
200
K
300
K
400
K
600
K
800
K
900
K
1000
K
1200
K
Remark
Tray paper
feed unit
1 Paper pickup roller ✕  – – Replace at 100K of the tray
paper feed counter or 1 year of
use.
2 Paper feed roller ✕  – – 
3 Separation roller ✕  – – 
4 Transport roller 4 ✕
 – – 
5 Transport roller 2 ✕  – – 
6 Torque limiter ✕✕– ✕✕✕– ✕✕
7 Sensors ✕✕– ✕✕✕– ✕✕
– Paper guides – – Clean with alcohol.
g Check (Clean, replace, or adjust according to necessity.) Ũ : Clean
Ţ : Replace : Lubricateţ : Adjust ŭ
3
7
1
2
5
4
7
6
