Sharp MX-2314N Service Manual

MX-3114N MAINTENANCE 9 – 39
L. Other
23 cpm machine
26 cpm/31 cpm machine
Unit name
Parts work
sequence
Part name
When
calling
100
K
200
K
300
K
400
K
500
K
600
K
700
K
800
K
Remark
1 Ozone filter – – –  –– ––
2 Toner cartridge BK User replacement for every toner empty.
3 Toner cartridge C
4 Toner cartridge M
5 Toner cartridge Y
6 Waste toner box Replaced by the user when full is detected. Replacement reference: 50K
Unit name
Parts work
sequence
Part name
When
calling
200
K
300
K
400
K
600
K
800
K
900
K
1000
K
1200
K
Remark
1 Ozone filter – –  –  –  – 
2 Toner cartridge BK User replacement for every toner empty.
3 Toner cartridge C
4 Toner cartridge M
5 Toner cartridge Y
6 Waste toner box Replaced by the user when full is detected. Replacement reference: 50K
g Check (Clean, replace, or adjust according to necessity.) Ũ : Clean
Ţ : Replace : Lubricateţ : Adjust ŭ







Sharp MX-2314N Specifications

General

Print Technology	Laser
Print Speed	23 ppm
Print Resolution	600 x 600 dpi
Scan Resolution	600 x 600 dpi
Copy Speed	23 cpm
Copy Resolution	600 x 600 dpi
Fax Transmission Speed	33.6 Kbps
Duplex Printing	Yes
Connectivity	USB, Ethernet
Functions	Print, Copy, Scan, Fax
Paper Size	A3, A4, A5, B4, B5
Max Paper Size	A3
Original Size	A3
