MX-3114N MAINTENANCE 9 – 40
M. Option
(1) Stand/500 sheet paper drawer
Unit work
sequence
Unit name
Parts work
sequence
Part name
When
calling
At the
machine cycle
Remark
1 Tray 2 paper feed
unit
1 Paper pickup roller ✕  Replace at 100K of each tray paper feed counter
or 1 year of use.
2 Paper feed roller ✕ 
3 Separation roller ✕ 
4 Transport roller 1 ✕ 
5 Torque limiter ✕✕Replace at 100K of each tray paper feed counter.
6Sensors ✕✕
– Paper guides Clean with alcohol.
2 1CS drive unit 7 Gears (grease) ✕✕Apply to the specified position when checking.
HANARL FL-955R
8 Shafts (grease) ✕✕Apply to the specified position when checking.
FLOIL G-313S
g Check (Clean, replace, or adjust according to necessity.) Ũ : Clean
Ţ : Replace : Lubricateţ : Adjust ŭ
7
1
6
2
3
5
6
8
8
8
6
4
