Sharp MX-2314N Service Manual

MX-3114N OPERATIONAL DESCRIPTIONS 13 – 18
b. 26cpm/31cpm machine
Signal name Name Function/Operation
ADUM ADU motor Drives the transport roller in the ADU right paper exit section.
APPD1 ADU paper transport detector 1 Detects paper entry and paper pass in the ADU.
APPD2 ADU paper transport detector 2 Detects paper pass in the ADU transport roller 8.
DSW_ADU ADU paper guide open/close detector Detects open/close of the ADU paper guide.
