MX-3114N OPERATIONAL DESCRIPTIONS 13 – 19
B. Operational descriptions
• The paper transported from the fusing section is sent from transport roller 6 (which is driven by the ADU motor) to paper exit roller 1.
At that time, the paper passed under the gate.
• When POD1 detects the paper lead edge, the paper exit drive motor reverses.
• By reversion of the paper exit motor, the paper is sent to the ADU section. At that time, the paper passes over the ADU guide which fell by its
own weight.
• Transport rollers 7 and 8 are driven the ADU motor, and transport roller 9 by the transport motor. The paper is transported to the duplex
paper feed position.
• The paper is once stopped at the duplex paper feed position, and transported again to the inside of the machine.
PFM Transport motor Drives the transport rollers 5 and 9.
POD3 Paper exit detector 3 Detects paper transport to the right paper exit tray.
No. Name Function/Operation
1 Transport roller 7 (Idle) Apply a pressure to paper and the transport roller to provide the transport power of the transport roller
to paper.
2 Transport roller 7 (Drive) Transports paper transported from the switchback section to the transport roller 8.
3 Transport roller 8 (Idle) Apply a pressure to paper and the transport roller to provide the transport power of the transport roller
to paper.
4 Transport roller 8 (Drive) Transports paper transported from the transport roller 7 to the transport roller 9.
5 Transport roller 9 (Idle) Apply a pressure to paper and the transport roller to provide the transport power of the transport roller
to paper.
6 Transport roller 9 (Drive) Transports paper transported from the transport roller 8 to the transport roller 5.
7 Paper exit roller 3 (Drive) Discharges paper to the right paper exit tray.
8 Paper exit roller 3 (Idle) Apply a pressure to paper and the paper exit roller to provide the transport power of the paper exit roller
to paper.
Signal name Name Function/Operation
