Sharp MX-2314N Service Manual

MX-3114N OPERATIONAL DESCRIPTIONS 13 – 60
*1: The number in ( ) is the count-up number when the large-size count-up setting is changed to the single count-up with SIM26-5 (Mainte-
nance count (B/W, COL)).
*3: The number in ( ) is the count-up number when the large-size count-up setting is changed to the single count-up with SIM26-5 (Developer
count (B/W, COL)).
*4: The number in ( ) is the count-up number when the large-size count-up setting is changed to the single count-up with SIM26-5 (Total count
(B/W, COL)).
Drum cartridge print counter (K) All paper exit operations
completed
SIM22-13 SIM24-4 1 2(1)*1 1 2(1)*1 1 2(1)*1
Drum cartridge print counter (C) Color paper exit operations
completed
1 2(1)*1 1 2(1)*1 1 2(1)*1
Drum cartridge print counter (M) Color paper exit operations
completed
1 2(1)*1 1 2(1)*1 1 2(1)*1
Drum cartridge print counter (Y) Color paper exit operations
completed
1 2(1)*1 1 2(1)*1 1 2(1)*1
Main charger print counter (K) All paper exit operations
completed
1 2(1)*1 1 2(1)*1 1 2(1)*1
Main charger print counter (C) Color paper exit operations
completed
1 2(1)*1 1 2(1)*1 1 2(1)*1
Main charger print counter (M) Color paper exit operations
completed
1 2(1)*1 1 2(1)*1 1 2(1)*1
Main charger print counter (Y) Color paper exit operations
completed
1 2(1)*1 1 2(1)*1 1 2(1)*1
Drum blade print counter (K) All paper exit operations
completed
1 2(1)*1 1 2(1)*1 1 2(1)*1
Drum blade print counter (C) Color paper exit operations
completed
1 2(1)*1 1 2(1)*1 1 2(1)*1
Drum blade print counter (M) Color paper exit operations
completed
1 2(1)*1 1 2(1)*1 1 2(1)*1
Drum blade print counter (Y) Color paper exit operations
completed
1 2(1)*1 1 2(1)*1 1 2(1)*1
Ozone filter print counter All paper exit operations
completed
1 2(1)*1 1 2(1)*1 1 2(1)*1
Toner cartridge print counter (K) All paper exit operations
completed
SIM22-13 – 1 2(1)*4 1 2(1)*4 1 2(1)*4
Toner cartridge print counter (C) Color paper exit operations
completed
1 2(1)*4 1 2(1)*4 1 2(1)*4
Toner cartridge print counter (M) Color paper exit operations
completed
1 2(1)*4 1 2(1)*4 1 2(1)*4
Toner cartridge print counter (Y) Color paper exit operations
completed
1 2(1)*4 1 2(1)*4 1 2(1)*4
Counter name Count-up timing
Display
SIM
Reset
SIM
Count-up number
Simplex surface
print
Duplex surface print
Paper feed tray -
Paper exit
completed
Paper feed tray -
ADU paper entry
completed
ADU paper feed -
Paper exit
completed
Small
size
Large
size
Small
size
Large
size
Small
size
Large
size

Sharp MX-2314N Specifications

General

Print Technology	Laser
Print Speed	23 ppm
Print Resolution	600 x 600 dpi
Scan Resolution	600 x 600 dpi
Copy Speed	23 cpm
Copy Resolution	600 x 600 dpi
Fax Transmission Speed	33.6 Kbps
Duplex Printing	Yes
Connectivity	USB, Ethernet
Functions	Print, Copy, Scan, Fax
Paper Size	A3, A4, A5, B4, B5
Max Paper Size	A3
Original Size	A3
