1-7
BEFORE USING THE MACHINE►BEFORE USING THE MACHINE
SIDE AND BACK
(1) LAN connector
Connect the LAN cable to this connector when the
machine is used on a network.
Use a shielded LAN cable.
(2) Extension phone socket (TEL)*
When the fax function of the machine is used, an
extension phone can be connected to this jack.
(3) Telephone line socket (LINE)*
When the fax function of the machine is used, the
telephone line is connected to this socket.
(4) Power plug
* Optional
To Next Page
