BEFORE USING THE MACHINE►MAINTENANCE
CLEANING THE MAIN CHARGER OF THE
PHOTOCONDUCTIVE DRUM
If black lines or colored lines appear even after you have cleaned the document glass and automatic document feeder,
use the charger cleaner to clean the main charger that charges the photoconductive drum.
1
Open the front cover.
2
Remove the toner collection container.
Press the release buttons on the sides of the toner collection
container and pull out slowly.
3
Remove the charger cleaner.
The charger cleaner is attached to the front cover.
(1) Push the right-hand side of the charger
cleaner to detach it from the hook.
(2) Put it over the hook to place it on the near
side.
(3) Turn the charger cleaner around the boss
to detach it from the left hand hook.
To Next Page
