BEFORE USING THE MACHINE►LOADING PAPER
IMPORTANT POINTS ABOUT PAPER
NAMES AND LOCATIONS OF TRAYS
THE DEFINITION OF "R" IN PAPER SIZE
To indicate the landscape setting, "R" is added to the end of the name of a paper size enabled for both landscape and
portrait settings.
LOADING PAPER
Paper that can be set either in the portrait or landscape orientation Paper that can only be set in the
landscape orientation
8-1/2" x 11" A4, B5 12" x 18", 11" x 17", 8-1/2" x 14", 8-1/2" x
13", SRA3, A3W, A3, SRA4, B4
Paper set in the landscape orientation Paper set in the portrait orientation Can be placed only in the landscape
orientation
Tray 1
Tray 2
(when a stand/550/2x550/3x550/2100 sheet
paper drawer is installed)
Tray 3
(Stand/2000 sheet paper
drawer)
Bypass tray
Tray 4
(Stand/2000 sheet paper
drawer)
Tray 3
(when a stand/2x550/3x550 sheet paper
drawer is installed)
Tray 4
(when a stand/3x550 sheet paper drawer
is installed)
