Sharp MX-3070N

7-45
SYSTEM SETTINGS►USER CONTROL
Network Status
The Network Status screen shows the general status information and the statuses relevant to, TCP/IP, DNS, and WINS
protocols.
Item Description
General
Displays the information common to the network.
• Connection Type: Displays the network connection type.
• Link Status: Displays the data transfer rate of the NIC and cable
information.
• Duplex Mode: Displays the duplex mode of the NIC.
• Hardware Address: Displays the MAC address of the NIC.
• Device Name: Displays the device name.
• Domain Name: Displays the domain name.
• Reception Level (Max. 100): Displays the reception level of the wireless LAN.
(When connected to a wireless network)
TCP/IP
Displays the current status of the TCP/IP protocol.
• IPv4 Settings: Displays the IPv4 protocol settings.
• DHCP: Selects whether or not the IP address is obtained from
the DHCP server.
• IPv4 Address: Displays the IPv4 address to which the notification is
sent.
• Subnet Mask: Displays the current subnet mask.
• Default Gateway: Displays the current default gateway.
• IPv6 Settings: Displays the IPv6 status.
• IPv6: Displays whether IPv6 is enabled.
• DHCPv6: Displays the status of the DHCPv6 server.
• Manual Address: Displays the IPv6 address that has been manually
specified.
• Default Gateway: Displays the current default gateway.
• Link-Local Address: Displays the link-local address.
• Stateless Address 1: Displays the stateless address.
• Stateless Address 2: Displays the stateless address.
• Stateful Address: Displays the stateful address.
DNS
Displays the status of the DNS server.
• IPv4/IPv6 Settings:
• Primary Server: Displays the current IP address of the primary DNS
server.
• Secondary Server: Displays the current IP address of the secondary DNS
server.
• Domain Name: Displays the current domain name of the DNS server.
WINS
Displays the status of the WINS server.
• Primary Server: Displays the current IP address of the primary WINS
server.
• Secondary Server: Displays the current IP address of the secondary WINS
server.
• Primary Server (DHCP): Displays the current IP address of the primary WINS
server (DHCP).
• Secondary Server (DHCP): Displays the current IP address of the secondary WINS
server (DHCP).
• Scope ID: Displays the current WINS scope ID.
• Scope ID (DHCP): Displays the current WINS scope ID (DHCP).
