MX-M264U SIMULATION 6 – 56
50-5
Purpose
Adjustment
Function (Purpose)
Used to adjust the print lead edge image
position. (PRINTER MODE)
Section
Operation/Procedure
1) Select a target adjustment item (DEN-C) with scroll key on the
touch panel.
2) Enter the adjustment value using the 10-key.
3) Press [EXECUTE] key.
The set value is saved, and the adjustment check pattern is
printed.
4) Measure the distance from the paper lead edge the adjustment
pattern to the image lead edge, and check to confirm that it is
in the standard adjustment value range.
Standard reference value: 4.0mm or less
When the adjustment value is increased, the distance from the
paper lead edge to the image lead edge is increased. When the
adjustment value is decreased, the distanced is decreased.
When the set value is changed by 1, the distance is changed by
about 0.1mm.
When the adjustment value is increased, the distance from the paper lead edge to the image lead edge is increased. When the adjustment
value is decreased, the distance from the paper lead edge to the image lead edge is decreased.
When the set value is changed by 1, the distance is changed by about 0.1mm.
Item/Display Content
Setting
range
Default
value
NOTE
A DEN-C Used to adjust the print lead edge image
position.
(PRINTER MODE)
1 - 99 30 Adjustment value too align the print lead edge for the
printer. When the adjustment value of this item is
decreased by 1, the printer print start position in the paper
transport direction is shifted to the lead edge by 0.1mm.
B DEN-B Rear edge void area adjustment 1 - 99 30 Void amount generated at the paper rear edge. When the
adjustment value of item B (DEN-B) is decreased by 1, the
print area adjustment value in the sub scanning direction
for the paper transport direction is decreased by 0.1mm.
C FRONT/REAR FRONT/REAR void area adjustment 1 - 99 20 Adjustment of the void amount generated on the left and
right edges of paper. When the adjustment value is
increased, the void amount is increased.
D DENB-MFT Manual feed rear edge void area adjustment
correction value
1 - 99 57
E DENB-CS1 Tray 1 rear edge void area adjustment
correction value
1 - 99 50
F DENB-CS2 Tray 2 rear edge void area adjustment
correction value
1 - 99 57
G DENB-CS3 Tray 3 rear edge void area adjustment
correction value
1 - 99 57
H DENB-CS4 Tray 4 rear edge void area adjustment
correction value
1 - 99 57
I DENB-ADU ADU rear edge void aria adjustment
correction value
1 - 99 60
J DENB-HV Heavy paper correction value 1 - 99 50
K MULTI COUNT Number of print 1 - 999 1
L PAPER MFT Tray selection Manual paper feed 1 - 5 1 2 (CS1)
CS1 Tray 1 2
CS2 Tray 2 3
CS3 Tray 3 4
CS4 Tray 4 5
M DUPLEX YES Duplex print selection Yes 0 - 1 0 1 (NO)
NO No 1
