MX-M264U SIMULATION 6 – 70
64-6
Purpose
Operation test/check
Function (Purpose)
Printer test print. (Self print) (PS)
Section
Operation/Procedure
1) Set the print conditions.
Select an item to be print condition with scroll keys.
Change the set values with 10-key.
2) Press [EXECUTE] key.
The test print (self print) is performed.
Print pattern of Item A
65
65-1
Purpose
Adjustment
Function (Purpose)
Used to adjust the touch panel (LCD dis-
play section) detection coordinates.
Section
Operation panel section
Operation/Procedure
Touch the center of the cross mark at the four corners of the
screen.
When the adjustment is completed normally, the screen shifts to
the simulation sub number entry menu.
In case of an error, the screen returns to the adjustment menu.
65-2
Purpose
Operation check/test
Function (Purpose)
Used to display the touch panel (LCD dis-
play section) detection coordinates.
Section
Operation/Procedure
Touch the touch panel.
The coordinates X (horizontal direction) and Y (vertical direction) of
the touched position is displayed in real time.
Item/Display Content Setting range Default value
A PRINT PATTERN Print pattern specification 1 1
B MULTI COUNT Number of print 1 - 999 1
C PAPER MFT Paper feed tray
selection
Manual paper feed 1 2
(CS1)
CS1 Tray 1 2
CS2 Tray 2 3
CS3 Tray 3 4
CS4 Tray 4 5
D PAPER TYPE PLAIN Paper type Standard paper 0 0
(PLAIN)
HEAVY Heavy paper 1
E TONER SAVE MODE OFF Monochrome toner
save
not set. 0 0
(OFF)
ON set. 1
Pattern No. Content
1B/W
;<
To Next Page
