MX-M264U SIMULATION 6 – 71
65-5
Purpose
Operation check/test
Function (Purpose)
Used to check the operation panel key
input.
Section
Operation/Procedure
Press the keys sequentially according to the guidance displayed on
the screen.
If the key entry is effective, the guidance for pressing the next key
is displayed. When all the key entries are completed, "COMPLETE"
is displayed.
<Check target key>
66
66-1
Purpose
Setting
Function (Purpose)
Used to display the FAX-related soft SW (2
- 150) on the LCD to allow changing the
soft SW while checking with the LCD.
Section
FAX
Operation/Procedure
1) Enter the [SW NO] with 10-key.
* When [C] key is pressed, the entered value of [SW NO] is
cleared.
2) Press [DATA] button.
The soft SW data entered in procedure 1) is displayed.
* When [SW NO] button is pressed, the display returns to the
initial screen.
3) Enter the number corresponding to the bit to be changed with
10-key.
*[1] [0]
[0] [1]
4) When [EXECUTE] button is pressed, it is highlighted and the
setting is saved.
After saving the setting, [EXECUTE] button returns to the nor-
mal display.
66-2
Purpose
Setting
Function (Purpose)
Used to enter a country code and set the
default value for the country code.
Section
FAX
Operation/Procedure
1) When the machine enters Simulation 66-02, the following
screen is displayed.
* When [DEST CODE] button is pressed, the display is shifted
to the country code list screen.
* The currently set country code is displayed in the column of
"PRESENT:".
2) Enter the country code (8 digits) with 10-key([0]/[1]). The
entered country code is displayed in the column of "NEW:" and
[SET] key becomes active.
* When [C] key is pressed, the column of “NEW:” is cleared.
3) When [SET] button is pressed after entering the country code,
[EXECUTE] button becomes active. The country code is dis-
played in the column of "PRESENT:", and the column of
"NEW:" is cleared.
4) When [EXECUTE] button is pressed, it is highlighted and
[YES] and [NO] buttons become active. The country name is
displayed on the tile line.
5) When [YES] button is pressed, it is highlighted and the soft SW
corresponding to the country code is initialized.
6) After completion of initialization of the soft SW, [EXECUTE],
[YES], and [NO] buttons become inactive.
Operation/Procedure (Shifting to the country page)
* When [DEST CODE] button is pressed on the initial screen, the
display is shifted to the country code list screen.
Use scroll keys to select the country select page.
Country code list
JOB STATUS
SYSTEM SETTINGS
HOME
1
2
3
4
5
6
7
8
9
AUDIT CLEAR
0
PROGRAM
CLEAR
STOP
CLEAR ALL/RESET
START (MONO)
JAPAN 00000000
U.S.A. 10110101
AUSTRALIA 00001001
U.K. 10110100
FRANCE 0011110 1
GERMANY 00000100
SWEDEN 10100101
NEWZEALAND 01111110
CHINA 00100110
SINGAPORE 10011100
TW 11111110
MIDDLEANDNEAREAST 11111101
SLOVAKIA 11111100
OTHER3 11111 011
FINLAND 00111100
NORWAY 10000010
DENMARK 00110001
NETHERLANDS 01111011
ITALY 01011001
SWITZERLAND 10100110
AUSTRIA 00001010
INDONESIA 01010100
THAILAND 10101001
MALAYSIA 01101100
INDIA 01010011
PHILIPPINES 10001001
HONGKONG 01010000
RUSSIA 10111000
SOUTHAFRICA 10 011111
SPAIN 10100000
PORTUGUESE 10001011
LUXEMBURG 01101001
BELGIUM 00001111
CZECH 00101110
HUNGARY 01010001
To Next Page
