MX-M264U SIMULATION 6 – 73
66-8
Purpose
Operation test/Check
Function (Purpose)
Used to send the selected sound mes-
sages to the line and the speaker. (Send
level: Max.)
Section
FAX
Operation/Procedure
1) When the machine enters Simulation 66-08, the following
screen is displayed.
2) When the sound message button to be sent is selected, it is
highlighted and the previously set button returns to the normal
display.
<Sound message table>
66-9
Purpose
Operation test/Check
Function (Purpose)
Used to send the selected sound message
to the line and the speaker. (Send level:
Soft SW setting)
* For details of sound messages, refer to
the sound message table of SIM66-08.
Section
FAX
Operation/Procedure
1) When the machine enters Simulation 66-09, the following
screen is displayed.
2) When a button of a sound message to be sent is selected, it is
highlighted and the previously set button returns to the normal
display.
3) When [EXECUTE] button is pressed, it is highlighted and a
sound message is sent.
4) To end signal send:
When [EXECUTE] button is pressed, it is highlighted and sig-
nal send is interrupted.
66-10
Purpose
Data clear
Function (Purpose)
Used to clear the FAX and image send
image data. (The confidential data are also
cleared.)
Section
FAX
Operation/Procedure
1) Press [EXECUTE] button.
2) Press [YES] button.
3) After completion of clearing, press [CA] key to reboot the
machine.
66-11
Purpose
Operation test/Check
Function (Purpose)
Used to send the selected signal at 300bps
to the line and the speaker. (Send level:
Max.)
Section
FAX
Operation/Procedure
1) When the machine enters Simulation 66-11, the following
screen is displayed.
2) When a button of a sound message to be sent is selected, it is
highlighted and the previously set button returns to the normal
display.
3) When [EXECUTE] button is pressed, it is highlighted and a
sound message is sent.
4) To end signal send:
When [EXECUTE] button is pressed, it is highlighted and sig-
nal send is interrupted.
300bps send signal table
66-12
Purpose
Operation test/Check
Function (Purpose)
Used to send the selected signal at 300bps
to the line and the speaker. (Send level:
Soft SW setting)
* For the kings of send signals at 300bps,
refer to SIM66-11, 300bps send signal
table.
Section
FAX
Operation/Procedure
1) When the machine enters Simulation 66-12, the following
screen is displayed.
2) When a button of a sound message to be sent is selected, it is
highlighted and the previously set button returns to the normal
display.
3) When [EXECUTE] button is pressed, it is highlighted and a
sound message is sent.
4) To end signal send:
When [EXECUTE] button is pressed, it is highlighted and sig-
nal send is interrupted.
66-13
Purpose
Setting
Function (Purpose)
Used to register dial numbers for SIM66-
14/15/16, Dial test. (Up to 20 digits can be
registered.)
Section
FAX
Operation/Procedure
1) When the machine enters Simulation 66-13, the following
screen is displayed.
* The number saved in the memory is displayed in the column
of [PRESENT:]. (If there is no data, [-------] is displayed.)
2) Enter a number with 10-key.
The entered number is displayed in the column of [NEW:].
After entering 20 digits, 10-key is disabled (no response). Only
[C] key is enabled. (10-key [0] to [9], [*], [#], [C] key (back by
one digit))
3) When [SET] key is pressed after completion of entry, the
entered number is displayed (registered) in the column of
[PRESENT:]. The column of [NEW:] becomes blank.
NONE (Mute) PAUSE (Pause
melody)
MESSAGE1
(Message 1)
MESSAGE2
(Message 2)
MESSAGE3
(Message 3)
MESSAGE4
(Message 4)
MESSAGE5
(Massage 5)
MESSAGE6
(Message 6)
ALARM (Alarm) RINGER
(Ringing sound
(Speaker))
EXT.TEL.RING
ER (External
telephone call)
NO SIGNAL 11111 11110 00000
010101 00001
