Parameter Description
Parameters
101
5.22 The Voltage Signal Selection across Terminal 1-5 and the Target
Frequency(P.509, P.530)
P.509 “The maximum operation frequency of terminal 1-5 (the target frequency
is set by the input signal of terminal 1-5)
P.530 “The selection of voltage signal
across terminal 1-5”
Related parameters
P. 80~ P.84 , P. 86,P.126, P.550
Multi-function terminals selection
P. 79 Operation mode selection
P.189
Factory setting function
P.501 Function selection of terminal 4-5
The set value of P.509 is the target frequency value of the inverter when the input signal of
terminal 1-5 is 5V (10V).
Parameter
Factory
setting
Setting
range
Remarks
509
50Hz
1~650Hz
P.189=1
60Hz
P.189=0
530 0 0~5
0
The valid range of signal sampling (terminal 1-5) is
0~5V.
1
The valid range of voltage signal sampling (terminal
1-5) is 0~10V.
2
The valid range of voltage signal sampling (terminal
1-5) is 0~ -5V.
3
The valid range of voltage signal sampling (terminal
1-5) is 0~ -10V.
4
The valid range of voltage signal sampling (terminal
1-5) is -5~+5V.
5
The valid range of voltage signal sampling (terminal
1-5) is -10~+10V.
Please refer to the terminal 2-5 for the function setting of analog input terminal 1-5.
Note: 1. In “external mode”, “combined mode 2" or “combined mode 4”, if RH, RM, RL and REX are all
off, target frequency of the inverter will be set by the input signal across terminal 1-5/2-5/4-5. If
AU is “off”, please refer to P.500~P.502
.
2. RL, RM, RH, REX, AU, RT and RUN mentioned at the end of this section are the function names
of multi-function control terminal”. For the options and functions of multi-
function control
terminals, please refer to P.80~P.84P.86P.126P.550. For related wiring, please refer to Section
3.5.
3. The selection of range of voltage signal sampling across terminal 1-5 by parameter P.530 will
affect the parameters value of 1-5 terminal input signal in 5.58 section.
