5.53 Multi-Function Display (P.161)
P.161 “Multi-function display selection”
Parameter
Factory
setting
Setting
range
Remarks
161 0 0~21
0
Output voltage. (V)
1
Voltage between P and N terminals. (V)
2
Temperature rising accumulation rate of inverter. (%)
3
Target pressure of the constant pressure system. (%)
4
Feedback pressure of the constant pressure system.
(%)
5
Operation frequency. (Hz)
6
Electronic thermal accumulation rate. (%)
7
Signal value (V) of 2-5 simulating input terminals.
8
Signal value (mA) of 4-5 simulating input terminals.
(mA/V)
9
Output power (kW).
10
PG card’s feedback rotation speed. (Hz)
11
Positive and reverse rotation signal. Then 1 represents
positive rotation, 2 represents reverse rotation, and 0
represents stopping state.
12
NTC temperature (
℃
)
13
Electronic thermal accumulation rate of motor. (%)
14
Signal value of analog input terminal 1-5. (V)
15
Input frequency of terminal HDI. (kHz)
16
Real-time curling radius value. (mm)
17
Real-time line speed. (m/min)
18
Output torque of inverter (%)
19
External terminal input state(about the sort of
termina
l, please refer to the table of the special
monitor code in the communication part)
20
External terminal output state(about the sort
of terminal, please refer to the table of the special
monitor code in the communication part)
21
Actual working carrier frequency
Note: The multi-function display selection is realized in the monitoring voltage mode. Please refer to
Page42 for monitoring mode selection (4.1.3 Operation flow charts for monitoring mode with DU01).
