Parameter Description
5.39 Multi-function Terminal Function Selection
(P.80~P.84, P.86, P.126, P.550)
P.80~P.84, P.86, P.126, P.550 “Multi-function terminal function selection”
Relevant
Parameters
Corresponding
terminal
Factory
setting
Setting
range
Value
name
Function description Remarks
80 M0 2
0~40，
43~53，
55~56
0 STF
In “external mode”,
“combined mode 1”,
3”, and when STF is
on, the inverter runs
forward.
In
programmed
operation
used as the
terminal.
1 STR
In “external mode”,
“combined mode 1”,
3”, and when STF is
on, the inverter runs
forward.
In
programmed
operation
used as the
pause signal
terminal.
2 RL Multi-speed
Please refer
toP.4~P.6
for
multi-speed
3 RM Multi-speed
81 M1 3
0~40，
43~53，
55~56
4 RH Multi-speed
5 AU
In “external mode”,
"combined mode 2”
or “combined mode
4”, the inverter target
frequency is set by
the signal input
across terminal 4 -5.
Refer
to P.39
7 MRS
When MRS is “turned
on”, the output of the
terminated
immediately.
8 RT
When RT is “on”, the
characteristics are
the same as the
second function.
Refer
to P.44
