Primary Operation
4.2.7 Basic operation procedures for combined mode 3 (P.79=6)
The target frequency is determined by communication. When RL, RM, RH and REX of
multi-speed stage levels are “on”, the target frequency is determined by combination of
multi-speed stage levels (Please refer to P.4~P.6、P.80~ P.84、P.86、P.126、P.550). When external
JOG is “on”, the target frequency is determined by P.15. Acceleration / deceleration time is
set by the value of P.16. The inverter starting is activated by external terminals. The functions
of P.996, P.998, and P.999 can be accomplished by communication.
4.2.8 Basic operation procedures for combined mode 4 (P.79=7)
The target frequency of the inverter is determined by the external terminals’ “external
voltage signal”, “external current signal”, or “combination of multi-speed stage levels”. The
inverter starting is activated by communication (including “Reset”).
4.2.9 Basic operation procedures for combined mode 5 (P.79=8)
The target frequency is determined by DU01 operating panel. When RL, RM, RH and REX of
multi-speed stage levels are “on”, the target frequency is determined by combination of
multi-speed stage levels (Please refer to P.4~P.6、P.80~P.84、P.86、P.126、P.550). When external
JOG is “on”, the target frequency is determined by P.15. Acceleration / deceleration time is
set by the value of P.16. The inverter starting is activated by the external forward and reverse
terminals.
