Parameter Description
5.61 4-5 Terminal Input Signal (P.196~P.199, P.505)
P.196 “The setting corresponding to
the minimum current/voltage of
termianl 4-5”
P.197 “The setting corresponding to
the maximum current/voltage of
terminal 2-5”
P.198 “The minimum input
current/voltage of 4-5 terminal”
P.199 “The maximum input
current/voltage of 4-5 terminal”
P.505 “The bias rate of 4-5
current/voltage signal”
Related parameters
P. 17 “
The selection of signal
across terminal 4-5
”
P.80~P.84 , P.86
“Multi-function terminals selection”
P.39 “The maximum operation
frequency of terminal 4-5”
P.501 “Function selection of terminal 4-5”
Parameter Factory setting Setting range Remarks
196 0% -100%~100% Refer to P.194
197 100% -100%~100% Refer to P.195
198
4mA
0~20 Refer to P.192
199
20mA
0~20 Refer to P.193
505 0% -100%~100% Refer to P.139
<Setting>
• The setting of 4-5 terminal input current/voltage is similar to the setting of 2-5. And they also
have the same effect except that the terminal 4-5 can’t give the negative voltage and the
minimum input current is 4mA.
• Please refer to 5.21 The Voltage Signal Selection across Terminal 2-5 and Target
Frequency (P.38, P.73) for the setting of the input current/voltage across terminal 4-5.
Note: operating the 4-5 terminal function mentioned above, you must flip the switch SW2 to corresponding
position at first and make sure it matches the setting value of parameter P.17.
