Parameter Description
5.21 The Input Signal Selection across Terminal 4-5 and the Target
Frequency (P.17, P.39)
P.39 “The maximum operation
frequency of terminal 4-5 (the target
frequency is set by the input signal
of terminal 4-5)”
P.17 “The selection of
current/voltage signal across
terminal 4-5
● The set value of P.39 is the target frequency value of the inverter when the input signal of
terminal 4-5 is 20mA (5V/10V). The input signal across terminal 4-5 is switched by P.17 and
toggle switch SW2 on control board, please refer to note 4. When voltage signal is input to
the terminal 4-5 and the toggle switch SW2 is set to 0~10V, the effective range of voltage
signal sampling is determined by P.17, please refer to P.39.
Parameter Factory setting Setting range Remarks
39
50Hz
1~650Hz
P.189=1
60Hz P.189=0
17 0
0~2
(note 4)
0
the effective range of signal sampling
across terminal 4-5 is 4~20mA
。
1
the effective range of voltage signal
sampling across terminal 4-5 is 0~10V
。
2
the effective range of voltage signal
sampling across terminal 4-5 is 0
～
。
Related parameters
P. 80~ P.84 , P. 86,P.126, P.550
“Multi-function terminals selection”
P. 79 “Operation mode selection”
P.189
“
Factory setting function
”
P.501 “Function selection of terminal 4-5”
