5.35 Stop or Reset Function Selection (P.75)
P.75 “Stop or reset function selection”
Parameter Factory setting Setting range Remarks
75 1 0, 1 ---
<Setting>
• When P.75=0, it is only suitable for the PU and H2 mode (combined mode 2). Press
STOP
STOP
RESET
RESET
to
stop the operation.
• When P.75=1, it is only suitable for the chosen mode. Press
STOP
STOP
RESET
RESET
to stop the motor.
• When the alarm goes off, press
STOP
STOP
RESET
RESET
for 1 second to reset the inverter.
Note: 1. In normal or abnormal condition reset the inverter by parameter P.997.
2. There are two built-in programs simulating the thermally-accumulating relay in the inverter,
namely, the "electronic thermal relay” and “IGBT module thermal relay”. After resetting the
inverter, the values of the two relays of “electronic thermal relay” and “IGBT module thermal
relay” will be set to zero.
3. In any modes except the PU and the H2 mode and when P.75=1, the motor can be stopped by
pressing
STOP
STOP
RESET
RESET
. The inverter then displays E0 and all functions of the inverter are disabled. To restart
in the external mode, follow the procedures below:
Press
PU
(The external STF/STR reference will remove E0 to continue the operation).There is a
start signal in the programmed operation mode. Once E0 is removed, the inverter will run at the
section where it stopped after reset.)
4. To remove E0 in other modes, please turn the power off and on.
5.36 Parameters Write Protection (P.77)
P.77 “Parameters write protection”
<Setting>
• If P.77=0 and the motor stops, all parameters can be rewritten except P.188 and P.90.
When the motor is running, only P.4~P.6, P.24~P.27, P.54~P.56, P.77, P.131~P.138,
P.142~P.149, P.161, P.187, P.190~P.199, P.221~P.225, P.230, P.232, P.288, P.290,
P.510~P.525, P.535~538, P.401 and P.605.
• If P.77=1 and when the motor stops, only P.77 and P.79 can be rewritten. When the motor is
running, parameter-writing is forbidden except P.77 and P.79.
• If P.77=2 and when the motor stops, all parameters can be written except P.188 and P.90.
When the motor is running, some parameters, including P.22, P.72, P.78, P.79,
P.90, P.155, P.160, P.188, P.402、P.403 cannot be written.
Parameter
Factory setting
Setting range
Remarks
77
0
0~2
，
4
---
