Shihlin electric SF-GT Series User Manual

Parameter Description
Parameters
159
• When P.245=1 or 11, turning on the power will turn on the fan. When the power is turned off,
the fan will be off, too.
• When P.245=2 or 12, the fan will be turned on if the temperature of the heat sink is higher
than 40℃. When the power is turned off, the fan will be turned off, too.
• When P.245=3 or 13, the fan will be turned on when the temperature of the heat sink is
higher than 60℃. When the temperature of the heat sink is lower than 40℃, the fan will be
turned off.
Note: please refer to the parameter P.40, P.85, P.129, P.130.
5.67 Modulation Coefficient (P.246)
P.246 "Modulation coefficient”
Parameter Factory setting Setting range Remarks
246 1 0.90~1.20 ---
<Setting>
• P.246 is used to determine the ratio between the maximum output voltage and the input
voltage. The users can use this parameter to obtain an output voltage that is higher than
the input voltage. But the output voltage waveform at this point will generate distortion and
contain assorted harmonics. It may also increase the motor torque harmonics and noises.
5.68 Commercial Power Supply Frequency Operation Function
(P.247~P.250)
P.247 “MC switchover interlock time”
P.248 “Start waiting time”
P.249 “Automatic switchover frequency from inverter to commercial power
supply frequency”
P.250 “Automatic switchover frequency range from commercial power supply to
inverter”
Parameter Factory setting Setting range Remarks
247 1s 0.1~100s ---
248 0.5 s 0.1~100 s ---
249 99999 0~60Hz, 99999 ---
250 99999 0~10Hz, 99999 ---

Shihlin electric SF-GT Series Specifications

General

Frequency	50/60 Hz
Power Range	0.4kW ~ 630kW
Cooling Method	Forced air cooling
Output Frequency	0~400Hz
Control Method	V/F control, Sensorless Vector Control, Torque control
Overload Capacity	150% for 60 seconds
Braking Unit	Built-in
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Short Circuit
Communication	Modbus RTU, Profibus DP, CANopen
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +60°C
Altitude	Below 1000m (derating required above 1000m)
Efficiency	98%
Humidity	Less than 95% RH (non-condensing)
Dimensions	Varies by model
Weight	Varies by model
Series	SF-GT Series
