Shihlin electric SF-GT Series User Manual

Appendix 1 Parameter Table
Parameter Table
197
Appendix 1 Parameter Table
Parameter
Number
Name Setting Range
Minimum
Setting Unit
Default Value
User
Setting
Value
Reference
Page
P.0 Torque boost 0~30% 0.1%
Model-based
(Note 1)
P56
P.1
Maximum frequency
0~120Hz 0.01Hz
120Hz
(55kW or below)
P57
60Hz
(75kW or above)
P.2
Minimum frequency
0~120Hz 0.01Hz 0Hz P57
P.3
Base frequency
0~650Hz 0.01Hz
50Hz/60Hz
(Note 2)
P58
P.4
Speed 1 (high speed)
0~650Hz 0.01Hz 60Hz P59
P.5
Speed 2 (medium
spe
ed)
0~650Hz 0.01Hz 30Hz P59
P.6
Speed 3 (low speed)
0~650Hz
0.01Hz
10Hz
P59
P.7
Acceleration time
0~360s/
0~3600s
0.01s/0.1s
5s (3.7Kw or below)
P60
20s (5.5Kw or above)
P.8
Deceleration time
0~360s/
0~3600s
0.01s/0.1s
5s (3.7Kw or below)
P60 10s (5.5~7.5kW)
30s (11Kw or above)
P.9
Electronic thermal relay
capacity
0~500A 0.01A
Motor rated current
(Note 1)
P62
P.10
DC injection brake
operation frequency
0~120Hz 0.01Hz 3Hz P63
P.11
DC injection brake
operation time
0~60s 0.1s 0.5s P63
P.12
DC injection brake
operation voltage
0~30% 0.1%
4%
(7.5kW or below)
P63 2%(11kW~55kW)
1%
(75kW or above)
P.13
Starting frequency
0~60Hz 0.01Hz 0.5Hz P64
P.14
Load pattern selection
0~13
1
0
P64
P.15
JOG frequency
0~650Hz 0.01Hz 5Hz P67
P.16
JOG acceleration
/deceleration time
0~360s/
0~3600s
0.01s/0.1s 0.5s P67
