Shihlin electric SF-GT Series User Manual

Appendix 1 Parameter Table
Parameter Table
198
Parameter
Number
Name Setting Range
Minimum
Setting
Unit
Default
Value
User
Setting
Value
Reference
Page
P.17
The selection of currnt/voltage
signal across terminal 4
-5
0~2 1 0 P99
P.18
High speed maximum
frequency
120~650Hz 0.01Hz 120Hz P57
P.19
Base frequency voltage
0~1000V, 99999
0.1V
99999
P58
P.20
Acceleration / deceleration
reference frequency
1~650Hz 0.01Hz
50Hz/60Hz
(Note 2)
P60
P.21
Acceleration/
deceleration time increments
0、1 1 0 P60
P.22
Stall prevention operation level
0~400% 0.1% 150% P67
P.23
Compensation factor at level
reduction
0~150%, 99999 0.1% 99999 P67
P.24
Speed 4
0~650Hz, 99999 0.01Hz 99999 P59
P.25
Speed 5
0~650Hz, 99999
0.01Hz
99999
P59
P.26
Speed 6
0~650Hz, 99999 0.01Hz 99999 P59
P.27
Speed 7
0~650Hz, 99999 0.01Hz 99999 P59
P.28
Output frequency filter constant
0~31
1
0
P69
P.29
Acceleration/ deceleration
curve selection
0~3 1 0 P69
P.30
Regenerative brake function
selection
0, 1 1 0 P73
P.31
Carrier operation selection
0~2 1 0 P74
P.32
Serial communication Baud
rate selection
0, 1, 2 1 1 P74
P.33
Communication protocol
selection
0, 1 1 1 P74
P.34
Reserved
P.35
Communication
mode
operating instruction and speed
instruction selection
0,1 1 0 P95
P.36
Inverter station number
0~254 1 0 P74
P.37
Speed display
0~5000.0r/min 0.1r/min
0 r/min P95
0~9999 r/min
1 r/min
P.38
The maximum output frequency
(the target frequency is set by
the input signal across terminal
2-5)
1~650Hz 0.01Hz
50Hz/60Hz
(Note 2)
P97
