Parameter Description
5.20 The Voltage Signal Selection across Terminal 2-5 and Target
Frequency (P.38, P.73)
P.38 “The maximum output frequency (the target frequency is set by the input
signal across terminal 2-5)”
P.73 “The selection of voltage signal
across terminal 2-5”
Related parameters
P. 80~ P.84 , P. 86,P.126, P.550
“Multi-function terminals selection”
P. 79 “Operation mode selection”
P.189
“
Factory setting function
”
P.500 “Function selection of terminal 2-5”
● The set value of P.38 is the target frequency value of the inverter when the input signal of
terminal 2-5 is 5V (10V).
Parameter
Remarks
38
50Hz
1~650Hz
P.189=1
60Hz P.189=0
73 0 0~5
0
The valid range of sign
al sampling (terminal
2-5) is 0~5V.
1
The valid range of voltage signal sampling
(terminal 2-5) is 0~10V.
2
The valid range of voltage signal sampling
(terminal 2-5) is 0~ -5V.
3
The valid range of voltage signal sampling
(terminal 2-5) is 0~ -10V.
4
The valid range of voltage signal sampling
(terminal 2-5) is -5~+5V.
5
The valid range of voltage signal sampling
(terminal 2-5) is -10~+10V.
<Setting>
Example 1: This example is the most commonly used method of adjustment. It is used when
the inverter is in the “external mode", “combined mode 2”or “combined mode 4”,
and the frequency are set by terminal 2-5.
