Shihlin electric SF-GT Series User Manual

Parameter Description
Parameters
60
Par
ameters
Target
frequenc
y
P.24=
99999
P.25=
99999
P.26=
99999
P.27=
99999
P.142=
99999
P.143=
99999
P.144=
99999
P.145=
99999
P.146=
99999
P.147=
99999
P.148=
99999
P.149=
99999
RL(P.6) ○ ○ ○ ○ ○ ○ ○ ○
RM(P.5) ○ ○ ○
RH(P.4) ○
For example, When P.26=99999, the target frequency is determined by RM (the set value
of P.5).
Note: 1. The multi-speed is only valid in the “external mode”, “combination mode 2”or “combined mode 4”.
2. RL, RM, RH, and REX mentioned in this section are the function names of the “multi-function
control terminal”. (For example, when P.80
=2, select the M0 terminal to perform the RL
(function).Please refer to P.80~P.8 4、P.86、P.126、P. 5 50 for function selection and purposes of the
multi-function control terminal. For related wiring, please refer to Section 3.5.
5.5 Acceleration / Deceleration Time (P.7, P.8, P.20, P.21,P.44 and P.45)
P.7 “Acceleration time”
P.8 “Deceleration time”
P.20 “Acceleration / deceleration
reference frequency”
P.21 “Acceleration / deceleration time
increments”
P.44 “The second acceleration time”
P.45 “The second deceleration time”
Related parameters
P. 47 “The second base frequency”
P. 3 “Base frequency”
P. 29 “Acceleration /deceleration
curve selection
”
P.80~P.84 , P.86, P.126, P.550
“Multi-function terminal selection”
P. 189 “Factory setting function”
● When the output frequency of the inverter is accelerated from 0Hz to P.20 (P.3), the
required time is defined as “acceleration time”.
● When the output frequency of the inverter is decelerated from 0Hz to P.20 (P.3), the
required time is defined as “deceleration time”.

Shihlin electric SF-GT Series Specifications

General

Brand	Shihlin electric
Model	SF-GT Series
Category	Inverter
Language	English
