Parameter Description
Parameters
109
5.27 AM2 Terminal (P.535 ~ P.538)
P.535 “AM2 output bias” P.536 “AM2 output gain”
P.537 “AM2 terminal function
selection”
P.538 “AM2 output terminal selection”
Parameter Factory setting Setting range Remarks
535 --- 0~2500 Factory default value
536 --- 0~2500 Factory default value
537 0 0~5 Refer to P.54
538 0 0, 2, 3
0
0~10V voltage is selected to be
outputted from the terminal AM2
2
0~20mA current is selected to be
outputted from the terminal AM2
3
4~20mA current is selected to be
outputted from the terminal AM2
Note: 1. Please refer to the instruction of AM1 for this terminal function. The operation of adjusting the bias
voltage and gain of AM2 is similar to AM1. P.535 corresponds to P.190, and P.536 corresponds to
P.191.
2. The output current/voltage of terminal AM2 is controlled by both the toggle switch SW5 on the
control board and the parameter P.538. The factory default value is 0~10V.
5.28 Restart Function (P.57, P.58, P.150 and P.160)
P.57 “Restart coasting time”
P.58 “Restart cushion time”
P.150 “Restart mode selection”
P.160 “Stall prevention operation level when restart”
Parameter Factory setting Setting range Remarks
57 99999 0~30s, 99999
99999：No restart function
58
5s(7.5kW or below)
0~60s --- 10s(11kW~55kW)
20s(75kW or above)
150 0 0~221 ---
160 100% 0~150%
Stall prevention operation level
when restarting the machine
