Shihlin electric SF-GT Series User Manual

Parameter Description
Parameters
96
5.19 Function Selection of HDI Terminal and Analog Terminal (P.500,
P.501, P.502, P.503)
P.500 “Function selection of terminal 2-5”
P.501 “Function selection of terminal 4-5”
P.502 “Function selection of terminal 1-5”
P.503 “Function selection of terminal HDI”
<Setting>
• When frequency reference is selected, 0～±10V/4~20mA corresponds to 0~the maximum
output frequency setting.
Note: 1. The default priority level of terminal function selection is 2-5 > 4-5 > 1-5 > HDI, so if you want to
set the terminal 1-5 as frequency reference, P.500 and P.501 should be set at 0 and P.502 should
be set at 1.
2. The function selection of terminal HDI (P.503) is only valid in the mode of tension.
Parameter
Factory setting
Setting range
Remarks
500 1
0~10
0
：
non-function
1：frequency reference
2：Torque reference
3：PID target value
4：PID feedback signal
5：target tension setting
6：line speed setting
7：feedback line speed
8：real-time curling radius
9：initial curling radius
10
：
material thickness
501 1
502 0
503 0
