Shihlin electric SF-GT Series User Manual

Parameter Description
Parameters
121
Relevant
Parameters
Corresponding
terminal
Factory
setting
Setting
range
Values
Function name
Function
description
Remarks
82 M2 4
0~40，
43~53，
55~56
9
EXJ
(External JOG)
In “external
mode" and
when EXJ is
“on”, the
target
frequency is
set byP.15
,
and the
acceleration
/
deceleration
time is set
by
P.16.
10 STF+EXJ
Multiplexed
function
The
multiplexed
function of
the
external
terminal is
the
complex of
several
basic
functions.
83 STF 0
0~40，
43~53，
55~56
11 STR+EXJ
12 STF+RT
13 STR+RT
14 STF+RL
15 STR+RL
84 STR 1
0~40，
43~53，
55~56
16 STF+RM
17 STR+RM
18 STF+RH
19 STR+RH
20 STF+RL+RM
21 STR+RL+RM
86 RES 30
0~40，
43~53，
55~56
22 STF+RT+RL
23 STR+RT+RL
24 STF+RT+RM
25 STR+RT+RM
26 STF+RT+RL+RM
27 STR+RT+RL+RM
28 RUN
In “external
mode” and
when Run is
“on", the
motor will
have a
forward
rotation.
