Parameter Description
Parameters
122
Relevant
Parameters
Corresponding
terminal
Factory
setting
Setting
range
Values
Function
name
Function description Remarks
126 M3 5
0~40，
43~53，
55~56
29 STF/STR
In “external
mode”, it is used
with RUN. The
inverter has a
reverse rotation
when STF/STR is
“on”, but a forward
rotation when
STF/STR is “off”.
Forward
/reverse
rotation
control
signal
30 RES
External reset
function
31 STOP
In “external
mode”, it can be
used as a
three-wire mode
with the RUN
signal or the
STF-STR terminal
(Note 4).
32 REX
Multi-speed set
(16 levels)
550 HDI 57
0~41，
43~57
33 PO
In “external mode"
and when PO is
“on”, programmed
operation mode is
chosen (Note 5).
34 RES_E
When alarms
occur, external
reset become
valid only when
the alarm goes
off.
35 MPO
In “external mode”
and when MPO is
“on”, the manually
operation cycle
mode is chosen.
36 TRI
When TRI is on,
triangle wave
function is
chosen.
