Shihlin Inverter Introduction
Note: 1.ND for Normal Duty，HD for Heavy Duty，the selection is decided by the setting value of P.186.
2.The test conditions of rated output current, rated output capacity and frequency converter inverter
power consumption are: the carrier frequency (P.72
) is at the set value
converter/inverter output voltage is at 440V; the output frequency is at 60Hz, and the ambient
temperature is 40℃.
Model SF-040-□□□K-GT
132 160 185 220
Applicable motor
capacity(kW)
ND 160 185 220 250
HD 132 160 185 220
Output
Rated output
Overload
120% 60 seconds (inverse time characteristics)
150% 60 seconds (inverse time characteristics)
Maximum output voltage Three-phase 380~480V
Power
supply
Rated power voltage Three-phase 380~480V 50Hz / 60Hz
Power voltage permissible
fluctuation
Three-phase 342~528V 50Hz / 60Hz
Power frequency
permissible fluctuation
±5%
capacity (kVA)
Cooling method Forced air cooling
Inverter weight kg 67 84 90 94
