Shihlin electric SF-GT Series User Manual

Shihlin Inverter Introduction
Inverter Introduction
12
Output
terminal
Multi-function
open collector
output
SO1-SE P.40
Inverter running (RUN), output frequency
detection (FU), Up to frequency (SU),
overload alarm (OL),
zero current detection
(OMD)
, alarm (ALARM), section detection
(PO1), periodical detection (PO2), and
pause detection (PO3), inverter output (BP),
work frequency output (GP).
SO2-SE
P.129
Multi-function
relay output
A1-B1-C1 P.85
A2-B2-C2
P.130
Analog output
AM1-5 P.54
Multi-function DC (0~10V/0~20mA
) output:
output voltage, current.
AM2-5 P.537
Pulse output HDO-SD
P.54
，P.74
Output the pulse which maximum frequency
is 100 kHz.
Operation
panel
Operation
monitoring
Output frequency monitoring, output current monitoring, output
voltage monitoring, abnormality record (Maximum 12 sets).
LED indication
lamp (8)
Forward rotation indication lamp, reverse rotation indication
lamp, frequency monitoring indication lamp, voltage monitoring
indication lamp, current monitoring indication lamp, mode
switching in
dication lamp, PU terminals control indication lamp,
and external terminals control indication lamp.
Communication function
RS-485 communication, can select Shihlin/Modbus
communication protocol.
Protection mechanism /
alarm function
Output short circuit protection, Over-current protection,
(+/P)-(-/N) over-voltage protection, under-
voltage protection,
motor over-heat protection (P.9), IGBT module over-
heat
protection, communication abnormality protection,
PTC
temperature protection etc.
Environment
Ambient
temperature
-10 ~ +40 ℃ (non-freezing).
Ambient
humidity
Below 90%Rh (non-condensing).
Storage
temperature
-20 ~ +65 ℃。
Surrounding
environment
Indoor, no corrosive gas, no flammable gas, no flammable
powder.
Altitude and
vibration
Altitude below 1000 meters, Vibration below 5.9m/s
2
(0.6G).
Grade of
protection
IP20
The degree
of
environment
al pollution
2
Class of
protection
Class I

Shihlin electric SF-GT Series Specifications

General

Brand	Shihlin electric
Model	SF-GT Series
Category	Inverter
Language	English
