Shihlin electric SF-GT Series User Manual

Appendix 1 Parameter Table
Parameter Table
203
Parameter
Number
Name Setting Range
Minimum
Setting Unit
Default Value
User
Setting
Value
Reference
Page
P.117
Acceleration/deceleration time
of Section 7
0~600s/0~6000s 0.01s/0.1s 0s P130
P.118
Acceleration/deceleration time
of Sec
tion 8
0~600s/0~6000s 0.01s/0.1s 0s P130
P.119
The dead time of positive and
reverse rotation
0~3000s 0.1s 0s P133
P.120
Output signal delay time
0~3600s
0.1s
0s
P102
P.121
Run direction in each section
0~255
1
0
P130
P.122
Cycle selection
0~8 1 0 P130
P.123
Acceleration/deceleration time
setting selection
0, 1 1 0 P130
P.124
Expansion board version
---
---
---
P146
P.126
Multi
-function terminal M3
function selection
0~40，43~53，
55~56
1 5 P120
P.128
Reserved
P.129
Multi
-function output terminal
SO2-SE function selection
0~10，16~19 1 2 P102
P.130
Function selection for
multi-function relay A2-B2-C2
0~10，16~19 1 0 P102
P.131
Frequency of section 1
0~650Hz 0.01Hz 0Hz P130
P.132
Frequency of section 2
0~650Hz
0.01Hz
0Hz
P130
P.133
Frequency of section 3
0~650Hz
0.01Hz
0Hz
P130
P.134
Frequency
of section 4 0~650Hz 0.01Hz 0Hz P130
P.135
Frequency of section 5
0~650Hz 0.01Hz 0Hz P130
P.136
Frequency of section 6
0~650Hz
0.01Hz
0Hz
P130
P.137
Frequency of section 7
0~650Hz 0.01Hz 0Hz P130
P.138
Frequency of section 8
0~650Hz 0.01Hz 0Hz P130
P.139
The bias rate of 2
-5 voltage
signal
-100.0%~100.0% 0.1% 0% P147
P.142
Speed 8
0~650Hz,99999
0.01Hz
99999
P59
P.143
Speed 9
0~650Hz , 99999 0.01Hz 99999 P59
P.144
Speed 10
0~650Hz , 99999 0.01Hz 99999 P59
P.145
Speed 11
0~650Hz , 99999 0.01Hz 99999 P59
