Shihlin electric SF-GT Series User Manual

Appendix 1 Parameter Table
Parameter Table
205
Parameter
Number
Name Setting Range
Minimum
Setting
Unit
Default Value
User
Setting
Value
Reference
Page
P.169
Output voltage 5 of middle
frequency
0~100% 0.1 0 P64
P.170
PID function selection
0
~3,12,13,21,23,31,32
1 0 P138
P.171
PID feedback control method
selection
0, 1 1 0 P138
P.172
PID proportion Gain
1~100
1
20
P138
P.173
PID integral Gain
0~100s
0.1s
1s
P138
P.174
PID differential Gain
0~1000ms 1ms 0 P138
P.175
Abnormal deviation level
0~100%
0.1%
0
P138
P.176
Exception duration time
0~600s 0.1s 30s P138
P.177
Exception handling mode
0, 1, 2 1 0 P138
P.178
Sleep detects deviation
0~100%
0.1%
0
P138
P.179
Sleep detects duration time
0~255s 0.1s 1s P138
P.180
Revival level
0~100% 0.1% 90% P138
P.181
Outage level
0~120Hz
0.01Hz
40Hz
P138
P.182
Integral upper limit frequency
0~200% 0.1% 100% P138
P.183
Deceleration step length with
stable pressure
0~10Hz 0.01Hz 0.5Hz P138
P.184
4
-5 terminal disconnection
handling
0~3 1 0 P144
P.185
Proportion linkage gain
0~100% 1% 0% P144
P.186
SF-GT Types Selection
0~1 1 1
P146
P.187
FM calibration parameter
0~9998 1 --- P105
P.188
Firmware
version --- --- --- P146
P.189
Factory setting function
0、1 1
60Hz
0
P146
50Hz 1
P.190
AM1 output bias
0~2500 1 --- P105
P.191
AM1 output gain
0~2500
1
---
P105
P.192
The minimum input positive
voltage of 2-5 terminal
0~10 0.01 0 P147
P.193
The maximum input positive
voltage of 2-5 terminal
0~10 0.01 5V P147
P.194
The
setting corresponding to
the minimum positive voltage of
termianl 2
-5
-100.0%~100.0% 0.1% 0.0% P147
