Appendix 4 Optional Equipment
Optional equipment
223
2. Operation panel, operation panels fixed base and the data transmission line
1). DU01S DU01 operation panel set(operation panel(DU01) and the fixed
base(GMB01))
Description on the ordering code:
NO. Model Item Name Ordering Code
1 DU01S DU01 operation panel set SNKDU01S
2
). CBL: Data transmission line (coordinated with the operation panel)
Description on the ordering code:
NO. Model Item name Ordering code
1 CBL1R5GT Data transmission line (Length: 1.5M) SNKCBL1R5GT
2 CBL03GT Data transmission line (Length: 3M) SNKCBL03GT
3 CBL05GT Data transmission line (Length: 5M) SNKCBL05GT

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Shihlin electric SF-GT Series and is the answer not in the manual?

Shihlin electric SF-GT Series Specifications

General IconGeneral
Frequency50/60 Hz
Power Range0.4kW ~ 630kW
Cooling MethodForced air cooling
Output Frequency0~400Hz
Control MethodV/F control, Sensorless Vector Control, Torque control
Overload Capacity150% for 60 seconds
Braking UnitBuilt-in
Protection FunctionsOvercurrent, Overvoltage, Undervoltage, Short Circuit
CommunicationModbus RTU, Profibus DP, CANopen
Operating Temperature-10°C to +50°C
Storage Temperature-20°C to +60°C
AltitudeBelow 1000m (derating required above 1000m)
Efficiency98%
HumidityLess than 95% RH (non-condensing)
DimensionsVaries by model
WeightVaries by model
SeriesSF-GT Series
