Shihlin electric SF-GT Series User Manual

Shihlin Inverter Introduction
Inverter Introduction
30
Terminal type
Terminal
name
Remarks and function description Terminal specification
Switch
Signal
Input
STF
The terminals are multi-
function control terminals,
their function can be set by
parameter P.80~P.84, P.86, P.126, P.550
. (The
SINK or SOURCE input approach can be
switched)
The terminal HDI can accept p
ulse signal (please
refer to the instruction of toggle switch SW11 and
the parameter P.550
), and the function of it can be
set by P.503.
Input impedance: 4.7 kΩ
Action current: 5mA
Voltage range: 20~28VDC
STR
RES
M0
M1
M2
M3
HDI
Maximum frequency:
100kHz
Analog
signal
input
10
The internal power is +12V at the terminal
Maximum current: 10mA
-10 The internal power is -12V at the terminal Maximum current: 10mA
1 The input terminals of voltage signal -10~10V.
They can be used to set the target frequency, and
the function can be set by parameter P.38, P.509.
Input impedance: 10kΩ
2
4
The input terminal of 4~20mA current signal or
0~10V voltage current.
It can be used to set the target frequency, and the
function can be set by parameter P.39.
When current is input into,
the input impedance is
235Ω.
When voltage is input into,
the input impedance is
24kΩ
PTC
The input of PTC temperature protection signal, the
function can be set by parameter P.534.
---
Relay
Output
A1
The terminals are multi-
function relay output
terminals, the function can be set by
parameter P.85, P.130.
A-C is normal open, B-
C is normal closed, and C is
the common port.
Maximum voltage:
30VDC or 250VAC
Maximum current: 2A
B1
C1
A2
B2
C2
Open collector
output
SO1
The terminals are the multi-
function open collector
ou
tput terminals, the function can be set by
parameter P.40, P.129.
Maximum voltage: 48VDC
Maximum current: 50mA
SO2
Analog signal
output
AM1
The terminals are the multi-function analog output
terminals. The external analog meter can be
connected to them to indicate the output frequency,
current, etc. The function can be set by
parameter P.54, P.64, P.537, P.538.
AM1 and HDO can not be used in the meantime,
please refer to the toggle switch SW12 instructions.
Output voltage: 0~10VDC
Maximum current: 3mA；
Output current: 0~20mA
Maximum load: 500Ω
AM2
