 AC output reactor
3-Phase, 440V, 50/60Hz
Inverter type
Recommended reactor
Shanghai Eagtop Type Shihlin Type
Rated
current
(A)
Inductance
(mH)
SF-040-1.5K-GT
OCL-0005-EISC-E2M8
SH-OCL-0005-02800
5
2.8
SF-040-2.2K-GT
OCL-0007-EISC-E1M9
SH-OCL-0007-01900
7
1.9
SF-040-3.7K-GT
OCL-0010-EISC-E1M4
SH-OCL-0010-01400
10
1.4
SF-040-5.5K-GT
OCL-0015-EISC-EM93
SH-OCL-0015-00930
15
0.93
SF-040-7.5K-GT
OCL-0020-EISC-EM70 SH-OCL-0020-00700 20 0.70
SF-040-11K-GT
OCL-0030-EISC-EM46
SH-OCL-0030-00460
30
0.46
SF-040-15K-GT
OCL-0040-EISC-EM35 SH-OCL-0040-00350 40 0.35
SF-040-18.5K-GT
OCL-0050-EISC-EM28
SH-OCL-0050-00280
50
0.28
SF-040-22K-GT(S)
OCL-0060-EISC-EM23
SH-OCL-0060-00230
60
0.23
SF-040-30K-GT
OCL-0080-EISC-EM17
SH-OCL-0080-00170
80
0.17
SF-040-37K-GT
OCL-0090-EISC-EM17
SH-OCL-0090-00170
90
0.17
SF-040-45K-GT
OCL-0120-EISC-EM11
SH-OCL-0120-00110
120
0.11
SF-040-55K-GT
OCL-0150-EISH-EM09
SH-OCL-0150-00090
150
0.09
SF-040-75K-GT
OCL-0200-EISH-EM07
SH-OCL-0200-00070
200
0.07
SF-040-90K-GT
OCL-0250-EISH-E55U SH-OCL-0250-00055 250 0.055
SF-040-110K-GT
SF-040-132K-GT
OCL-0330-EISH-E21U SH-OCL-0330-00021 330 0.021
SF-040-160K-GT
OCL-0390-EISH-E18U
SH-OCL-0390-00018
390
0.018
SF-040-185K-GT
OCL-0490-EISH-E14U SH-OCL-0490-00014 490 0.014
SF-040-220K-GT
OCL-0530-EISH-E13U
SH-OCL-0530-00013
530
0.013
