Parameter Description
Parameters
94
Parameter restoration condition table
Data
content
Parameter P
operation
Communication
Parameter P
(Note)
P.21, P.125, P.188~P.199
,
P.29 2, P.293, P.300~P.326 and
communication parameter P
excluded
Other P
parameters
Error
codes
H5A5A P.999 o o x x
H9966 P.99 9 o o o x
H9696
Communication
999
x o x x
H55AA
Communication
998
x o o x
HA5A5 P.99 9 x x x o
NoteCommunication P parameters include P.32, P.33, P.36, P.48~P.53, P.79, P.153 and P.154.
The table of the special monitor code
Information Content Unit
H0000 Monitor the external terminal input port state. Note1
H0001 Monitor the external terminal output port state. Note2
H0002 Monitor the voltage which can be input across terminal 2-5.
0.01V
H0003 Monitor the voltage/current which can be input across terminal 4-5.
0.01A/0.01V
H0004 Monitor the voltage which can be output across terminal AM1-5.
0.01V
H0005 Monitor the DC bus voltage value.
0.1V
H0006 Monitor the electronic thermal accumulation rate
---
H0007 The temperature rising accumulation rate of inverter
0.01
H0008 The inverter output power
0.01kW
H000A The electronic thermal accumulation rate of motor
---
H000B Target pressure when PID control
0.1%
H000C Feedback pressure when PID control
0.1%
H000D The rotating speed fed back by PG
0.01Hz
H000E The input frequency of terminal HDI
0.01kHz
H000F The input voltage of terminal 1-5
0.01V
H0010 The output voltage of terminal AM2-5
0.01V
Note1. Details of the external terminal input port state.
b0
b15
STFSTRM1 M0M2RESM3ReserveReserveHDI
2. Details of the external terminal output port state.
b0
b15
SO1A1B1C1A2B2C2 SO2ReserveReserve
