Chapter 8 Operating Instructions
M4000 Adv., Adv. A/P, Area
64 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 8010797/PA53/27-06-05
Configuration
8 Configuration
8.1 Default delivery status
As delivered the M4000 is configured ready for protective operation. In the following table
you will find all functions that can be configured as well as information on which device the
functions need to be configured.
• The preconfiguration of the M4000 multiple light beam safety device depends on the
type (see Ordering information on page 90ff).
• You can open the existing configuration of the M4000 at any time with the aid of the
CDS.
M4000 Advanced, M4000 Area 60/80 M4000 Advanced A/PFunction
Sender Receiver Sender and receiver
unit
Beam coding
External device
monitoring
–
Reset/restart
interlock
–
Scanning range –
Application
diagnostic output
(ADO)
–
Sender test ––
You will find more detailed information on the individual functions in chapter 4
“Configurable functions” on page 21ff.
8.2 Preparation of the configuration
How to prepare the configuration:
Make sure that the multiple light beam safety device has been correctly mounted and
that the electrical connections are correct and in place.
Plan all necessary settings (beam coding, scanning range, external device monitoring,
etc.) and document them.
For the configuration of the multiple light beam safety device you will need:
• CDS (Configuration & Diagnostic Software) on CD@ROM
• user manual for CDS on CD@ROM
• PC/Notebook with Windows 98/NT 4/2000 Professional/XP and a serial interface
(RS@232). PC/Notebook not included
• connecting cable between PC and M4000 (SICK-Part No. 6021195)
To configure the device, please read the user manual for the CDS (Configuration &
Diagnostic Software) and use the online help function of the programme.
Notes
configurable functions
