SICK M4000 Advanced Manual

Chapter 11 Operating Instructions
M4000 Adv., Adv. A/P, Area
82 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 8010797/PA53/27-06-05
Technical specifications
11.3.2 M4000 Passive
Fig. 49: Dimensional drawing
M4000 Passive (mm)
91.7
L2
52
Sliding nut
groove
for
side
mounting
14
6
10.5
2.2
3.5
1
27.5
S1
55.5
M4000
Passive
(mirror deflection)
72.3
14.5
S1
S1
L1
91.7
S1
L2
52
14.5
M4000
Passive
(fibre6optic deflection)
L1
AUDIN - 7 bis rue de Tinqueux - 51100 Reims - France - Tel : 03.26.04.20.21 - Fax : 03.26.04.28.20 - Web : http: www.audin.fr - Email : info@audin.fr

SICK M4000 Advanced Specifications

General

Type	Multiple light beam safety device
Enclosure rating	IP65
Supply voltage	24 V DC
Safety integrity level	SIL3
Performance level	PL e
Protection Rating	IP65
Operating Voltage	24 V DC
Number of beams	2 to 4 beams
Resolution	70 mm
Ambient operating temperature	-25 °C ... +55 °C
Angular Resolution	Not applicable
Operating Temperature	-25 °C ... +55 °C
