SICK M4000 Advanced Manual

Chapter 12 Operating Instructions
M4000 Adv., Adv. A/P, Area
98 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 8010797/PA53/27-06-05
Ordering information
12.6 Device columns
Description Part number
Device column with front plate, incl. mounting kit
Suitable for M40#-02500#### and M40#-02501####,
2@beam, 500 mm beam separation
2031438
Device column with front plate, incl. mounting kit
Suitable for M40E-02502#### and M40E-02503####,
2@beam, 500 mm beam separation
2032467
Device column with front plate, incl. mounting kit
Suitable for M40#-02600#### and M40#-02601####,
2@beam, 600 mm beam separation
2032969
Device column with front plate, incl. mounting kit
Suitable for M40#-02602#### and M40#-02603####,
2@beam, 600 mm beam separation
2032970
Device column with front plate, incl. mounting kit
Suitable for M40#-03400#### and M40#-03401####,
3@beam, 400 mm beam separation
2032465
Device column with front plate, incl. mounting kit
Suitable for M40E-03402#### and M40E-03403####,
3@beam, 400 mm beam separation
2032468
Device column with front plate, incl. mounting kit
Suitable for M40#-04300#### and M40#-04301####,
4@beam, 300 mm beam separation
2032466
Device column with front plate, incl. mounting kit
Suitable for M40E-04302#### and M40E-04303####,
4@beam, 300 mm beam separation
2032469
Device column with front screen, incl. mounting kit
Suitable for M4000 with max. device length (incl. connection cable) of
1200 mm
2018608
Device column with front screen, incl. mounting kit
Suitable for M4000 with max. device length (incl. connecting cable)
1500 mm
2031232
Device column with front screen, incl. mounting kit
Suitable for M4000 with max. device length (incl. connecting cable)
1700 mm
2018767
Adjusting plate
Suitable for mirror and device columns
4031053
Mounting bracket UE403 for device column
For fastening to base plate, including screw
2032035
12.7 Accessories
Part Part number
Mounting kits
Mounting kit 1: mounting bracket rigid, 4 pcs. 7021352
Mounting kit 2: mounting bracket pivoting, 4 pcs. 2017751
Tab.
51
:
Part numbers
device columns
Tab.
52
:
Part numbers
accessories
AUDIN - 7 bis rue de Tinqueux - 51100 Reims - France - Tel : 03.26.04.20.21 - Fax : 03.26.04.28.20 - Web : http: www.audin.fr - Email : info@audin.fr

SICK M4000 Advanced Specifications

General

Type	Multiple light beam safety device
Enclosure rating	IP65
Supply voltage	24 V DC
Safety integrity level	SIL3
Performance level	PL e
Protection Rating	IP65
Operating Voltage	24 V DC
Number of beams	2 to 4 beams
Resolution	70 mm
Ambient operating temperature	-25 °C ... +55 °C
Angular Resolution	Not applicable
Operating Temperature	-25 °C ... +55 °C
