Operating Instructions Chapter 12
M4000 Adv., Adv. A/P, Area
8010797/PA53/27-06-05 © SICK AG • Industrial Safety Systems • Germany • All rights reserved
99
Ordering information
Part Part number
Mounting kit 6: side bracket pivoting, 4 pcs. 2019506
Mounting kit 12: swivel@mount bracket, pivoting, 4 pcs 2030510
M4000 system connection
Hirschmann cable socket M26× 11 + FE, crimp contacts, straight 6020757
Hirschmann cable socket M26× 11 + FE, crimp contacts, angled 6020758
Terminal with 182 resistance for pin 9 and 10 on the system
connection (see page 45)
2027227
Connecting cable for M4000 with Hirschmann cable socket
M26× 11 + FE:
Socket straight, stripped, 2.5 m 2022544
Socket straight, stripped, 5 m 2022545
Socket straight, stripped, 7.5 m 2022546
Socket straight, stripped, 10 m 2022547
Socket straight, stripped, 15 m 2022548
Socket straight, stripped, 20 m 2022549
Socket straight, stripped, 30 m 2022550
M4000 extension connection
Connection cable for M4000 Advanced with 5@pin M12 plug and
UE403
Wire cross-section 0.34 mm², 5@pin M12 plug, 5@ pin M12 socket,
PUR halogen-free
Plug straight/socket straight, 0.6 m 6025930
Plug straight/socket straight, 1.0 m 6029280
Plug straight/socket straight, 1.5 m 6029281
Plug straight/socket straight, 2.0 m 6025931
Plug straight/socket straight, 5.0 m 6029282
Connection cable for PC
For the connection between PC and M4000 or UE403 6021195
External laser alignment aid
AR60 1015741
Adapter for M4000 housing 4040006
Accessories included in a standard delivery
CDS (Configuration & Diagnostic Software) on CD@ROM incl. Online
documentation and operating instructions in all available languages
2032314
Sliding nuts for mounting bracket/side bracket, 4 pcs 2017550
Alignment template for integrated laser alignment aid
33)
4040263
33)
Only with devices with integrated laser alignment aid.
