Technical specifications
11 Technical specifications
11.1 Data sheet
M4000 Advanced, M4000 Advanced A/P and M4000 Area 60/80
Minimum Typical Maximum
General system data
Number of beams, type-dependent
M4000 Advanced 2 12
M4000 Advanced A/P 24
Length of the monitored area,
depending on type
M4000 Area 60 300 mm 1800 mm
M4000 Area 80 600 mm 1800 mm
Beam separation, type-dependent
M4000 Advanced 120 mm 600 mm
M4000 Advanced A/P 500 mm and
300 mm
M4000 Area 60/80 50 mm 57 mm
Resolution, depending on type
M4000 Area 60/80 60 mm 80 mm
Scanning range, configurable
M4000 Advanced,
M4000 Area 80
Low scanning range 0.5 m 20 m
High scanning range 15 m 70 m
M4000 Area 60
Low scanning range 0.5 m 6 m
High scanning range 5 m19 m
Scanning range
3)
M4000 Advanced A/P
With mirror deflection 0.5 m 7.5 m
With fibre-optic deflection 0.5 m 4.5 m
Beam diameter
M4000 Advanced,
M4000 Advanced A/P and
M4000 Area 80
23 mm
M4000 Area 60 13 mm
3)
The scanning range of the M4000 Advanced A/P device must be configured to suit the deflection used (see
section 4.4.2 “Scanning range of the M4000 Advanced A/P” on page 26).
Advanced, M4000
Advanced A/P and M4000
Area 60/80
