Operating Instructions Chapter 12
M4000 Adv., Adv. A/P, Area
8010797/PA53/27-06-05 © SICK AG • Industrial Safety Systems • Germany • All rights reserved
93
Ordering information
M4000 Advanced A/P
with M26 Hirschmann plug,
M12× 5 socket
29)
and
end cap with integrated LED
30)
Type code Part
number
Type codeNumber
of
beams
Beam
separation
[mm]
M4000 Advanced A/P
M4000 Passive
M40Z-025023RB0 1027906 PSD01-1501
31)
2 500
M40Z-025023TB0 1027907 PSD01-2501
32)
4 300 M40Z-043023TB0 1027908 PSD02-2301
32)
12.2.3 Default delivery status
• The pre-setting for the device configuration is termed the default delivery status. You
can accept or change these pre-settings (see chapter 8 “Configuration” on page 64).
• The default delivery status is only applicable for the device types listed in
chapter 12.2.2 “Type code” on page 92ff.
ConfigurationFunction
M4000 Advanced A/P
Beam coding Non-coded
Restart interlock Internal
External device
monitoring (EDM)
Activated
Scanning range Preconfigured depending on type
Application
diagnostic output
(ADO)
Contamination
12.3 M4000 Area 60/80
12.3.1 Delivery
Sender Receiver
• sender unit
• 4 sliding nuts for side bracket
• receiver unit
• 4 sliding nuts for side bracket
• label “Important Information”
• operating instructions on CD@ROM
• CDS (Configuration & Diagnostic
Software) on CD@ROM
29)
Receiver only: extension connection for UE403.
30)
Receiver only.
31)
With mirror deflection (max. effective scanning range 7.5 m).
32)
With fibre-optic deflection (max. effective scanning range 4.5 m).
Advanced A/P with M26 plug
and end cap with integrated
LED
Notes
status M4000 Advanced A/P
M4000 Area 60/80
